I have a azure hosted api that accepts my webhook. What parameters are critical for this to work? There is woeful documentation on JSON produced form camera. Test page on clound says to add parameters but then says to remove for production?
Anyway to get to the snapshot photo based on the JSON produced?
Your camera can contact a webhook when an alarm was triggered. You can find some documentation here (your camera can use both the HTTP or MQTT protocol to contact the alarm server (in your case the hosted cloud service). The JSON payload is identical in both cases:
You can use a free platform like Node-RED to first test the function locally and make sure everything works as expected:
The function above only sends the alarm trigger and detected objects. A snapshot then has to be requested from your camera manually. Either send an HTTP GET request to one of those addresses - depending on the JPG resolution you need:
https://{camera address}:{camera webport}/snap.cgi?chn=11https://{camera address}:{camera webport}/snap.cgi?chn=12https://{camera address}:{camera webport}/snap.cgi?chn=13To get a base64 encoded snapshot use the following HTTP GET request:
https://{camera address}:{camera webport}/param.cgi?cmd=getsnapshotIf you plan on using MQTT connect your camera to your MQTT broker and subscribe to the MQTT alarmserver topics status/alarm/triggered/triggers & alarm/triggered/objects and the base64 snapshot topic task/photoseries/snap/base64
appreciate the info! how can i get snapshot from instar cloud? i dont want to dmz my internal cameras
Hey,
to access the Cloud API you - currently - have to manually create an access token:
https://api.cloud.instar.de/api/v1/token?username=xxxx@email.com&password=xxxxxxThe user name and password are the email address and pass you use to login to your Cloud account.
NOTE: You need to make your email address and password URL-safe before using them in a URL query!
The token - currently - defaults to a 2h expiration time. And the response to the above request looks like this:
{
"status": 0,
"message": "ok",
"data": {
"token": "baa0187e7f92b7216ac5f75e10890fdf1dd74d48",
"token_expiration_time": 1623754949
}
}
| Parameter name | Type | Description |
|---|---|---|
| status | Int | Error code, 0 means no errors happened |
| message | String | Error message |
| token | String | API token |
| token_expiration_time | Int | Token exipiration time, defaults to 2 hours |
After getting the token you can use it to access the list of alarms for your account:
https://api.cloud.instar.de/api/v1/alarm/list?page_no=1&page_size=1&token=xxxxxxThe example above uses two queries page_no and page_size to limit the response size - in this case you only get the latest alarm event recorded. You can use the following queries to customize the API request:
| Parameter | Required | Type | Description |
|---|---|---|---|
| token | Yes | String | You can get token by calling api User token |
| is_falsealarm | No | Int | Get falsealarm video or not, its value must be one of them: 0/1. 0 means get alarm video, 1 means get falsealarm video. Note: only is_falsealarm equals 0, then the filter person, vehicle, animal and unknown can be set as filter, otherwise the result will be empty |
| is_viewed | No | Int | Get viewed video or not, its value must be one of them: 0/1. 0 means unviewed video, 1 means get viewed video |
| is_locked | No | Int | Get locked or not, its value must be one of them: 0/1. 0 means unlocked video, 1 means get locked video |
| is_starred | No | Int | Get starred video or not, its value must be one of them: 0/1. 0 means unstarred video, 1 means get starred video |
| attr_link | No | Int | Combine locked and starred or not, its value must be one of them: 0/1. 0 means the result including locked or starred, 1 means the result including locked and starred |
| person | No | Int | Get video with person or not. its value must be 1. this means get video with person. Note: only is_falsealarm equals 0, then you can set this filter, otherwise, the result will be empty |
| vehicle | No | Int | Get video with vehicle or not. its value must be 1. this means get video with vehicle. Note: only is_falsealarm equals 0, then you can set this filter, otherwise, the result will be empty |
| animal | No | Int | Get video with animal or not. its value must be 1. this means get video with animal. Note: only is_falsealarm equals 0, then you can set this filter, otherwise, the result will be empty |
| unknown | No | Int | Get video with unknown or not. its value must be 1. this means get video with unknown. Note: only is_falsealarm equals 0, then you can set this filter, otherwise, the result will be empty |
| object_link | No | Int | Combine person, vehicle and animal or not, its value must be one of them: 0/1. 0 means the result including person or vehicle or animal (once they are set as above), 1 means the result including person and vehicle and animal (once they are set as above) |
| license | No | String | License number |
| date | No | String | The specific date, it will get all alarm of this day, eg: 2020-10-01. Note: if date is used, other date filter like start_date, end_date, start_time and end_time will be ignored |
| start_date | No | String | Start date, eg: 2020-10-18 |
| end_date | No | String | End date, eg: 2020-11-20 |
| start_time | No | String | Start time: 08:00 |
| end_time | No | String | End time: 18:00 |
| time_interval | No | Int | Use time as a daily period of time, its value must be 0/1. 0 means ger all videos from start time of start date to end time of end date. 1 means only get this alarm videos between start time and end time of every day |
| cam_id | No | Int | Camera id |
| camset_id | No | Int | Camera set id. Note: if camera set id used, camera id will be ignored. |
| page_no | No | Int | Page number |
| page_size | No | Int | Page size |
And a typical API response will look like:
{
"status": 0,
"message": "ok",
"data": {
"totalCount": 299,
"totalPages": 299,
"alarmList": [
{
"alarm_id": 1333410,
"start": "2020-11-18 16:36:04",
"cam_id": 482,
"name": "New one",
"object_detection": 0,
"is_viewed": 0,
"is_locked": 0,
"is_starred": 0,
"is_falsealarm": 1,
"object": 3,
"video": "https://api.cloud.instar.de/api/v1/video/alarm
/1333410.mp4",
"video_poster": "https://api.cloud.instar.de/api/v1/poster/
alarm/1333410.jpg"
}
]
}
}
| Parameter | Type | Description |
|---|---|---|
| status | Int | Error code, 0 means no errors happened |
| message | String | Error message |
| totalCount | Int | Total count of alarms |
| totalPages | Int | Total pages of alarms |
| alarmList | String | It is array, it includes all alarms list info, if there is no any alarms data, it will empty array |
| alarm_id | Int | Alarm id |
| start | String | The create time of alarm |
| cam_id | Int | Camera id |
| name | String | Camera name |
| object_detection | Int | If camera activated object detection or not, its value must be one of them: 0/1. 0 means deactivated, 1 means activated |
| is_viewed | Int | If alarm viewed or not, its value must be one of them: 0/1. 0 means unviewed, 1 means viewed |
| is_locked | Int | If alarm locked or not, its value must be one of them: 0/1. 0 means unlocked, 1 means locked |
| is_starred | Int | If alarm starred or not, its value must be one of them: 0/1. 0 means unstarred, 1 means starred |
| is_falsealarm | Int | If alarm is false alarm or not, its value must be one of them: 0/1. 0 means not false alarm, 1 means false alarm |
| object | Int | Which object detect in alarm video. its value must be one of them: -2/0/1/2/3/4/5/6/7, -2 means no object detection for alarm video, 0 means unknown, 1 means person, 2 means vehicle, 3 means person & vehicle, 4 means animal, 5 means person & animal, 6 means vehicle & animal, 7 means person, vehicle & animal. Note: only is_falsealarm equals 0, then object is valid. |
| video | String | Video link, need to added token after video link to access video. Like: https://api.cloud.instar.de/api/v1/video/alarm/1333410.mp4?token=xxxxx |
| video_poster | String | Video poster link, need to added token after video poster link to access the poster. Like: https://api.cloud.instar.de/api/v1/poster/alarm/1333410.jpg?token=xxxxxx |
To download either the alarm snapshot or the entire alarm video you need to attach the generated token to your request:
https://api.cloud.instar.de/api/v1/video/alarm/1333410.mp4?token=xxxxxxhttps://api.cloud.instar.de/api/v1/poster/alarm/1333410.jpg?token=xxxxxxThank you!! incredible documentation,
